Description
Expert in sticky smoke purification | Save 40% space + self-cleaning filter | [PURE-AIR]
[PURE-AIR] FGS-i series laser smoke purification equipment uses anti-stick pre-filter filter + 10KPa super vortex negative pressure to solve the problem of high-fat smoke clogging, 0.3 micron particle filtration efficiency 99.9%, workshop air direct exhaust compliance!
Innovative solution
- Sticky dust terminator
self-cleaning filter system
- Anti-stick pre-filter layer: actively rejects resin and rubber tar adhesion, and increases dust holding capacity by 3 times.
- Intelligent air volume compensation: filter blockage automatically compensates to the set air volume, and the smoking efficiency does not decrease.
- Space optimization master
free switching of multiple stations
- Anti-collision body saves 40% space, suitable for narrow workshops/multi-equipment clusters.
- Quick-install module + 360° industrial roller, complete production line migration in 10 seconds.
- Intelligent control center
full-dimensional control of purification efficiency
- 7-inch IoT touch screen: real-time tracking of PM2.5/VOC/temperature and humidity data, automatic alarm when exceeding the standard.
- AI working condition algorithm: intelligently adjust the air volume according to the processing material (800-2000m³/h).
- RS-485/MQTT protocol: seamlessly connect to MES system to achieve purification-production collaborative start and stop.
- Long-lasting economic design
operation and maintenance costs are cut in half
- Quadruple composite filter element, life is extended by 30%.
- 1-minute quick-disassembly structure: tool-free operation for element replacement.
- Cast aluminum volute + alloy impeller: 30,000 hours maintenance-free, stable operation.
Table Parameters：
| Model | PA-FGS800i | PA-FGS1600i | PA-FGS2400i | |
| Airflow | 800m³/hr | 1600m³/hr | 2400m³/hr | |
| Pressure | 10000Pa | 10000Pa | 10000Pa | |
| Rated power | 1.3kw | 2.3kw | 3.5kw | |
| Input voltage / Frequency | 90v-110v / 210-257v, 1ph, 50/60Hz | |||
| Filter | Pre filter | PTFE cartridge filter with natural mineral powder | ||
| Main filter | H14 deeppleat filter (99.997% @0.3um) | |||
| Treated activated carbon (Weight 12-30kgs approx) | ||||
| Noise level * | < 62dBA | < 65dBA | < 68dBA | |
| Dimensions (W*D*H) | 500*597*1439mm | 670*834*1705mm | 750*907*1698mm | |
| Weight | 128kg | 210kg | 241kg | |
| Inlet size | 100mm / 125mm | 150mm | 200mm | |
| Cabinet construction | Powder coated mild steel / Brushed stainless steel | |||
| * At typical operating speed testing data. | ||||
